The Pepperl+Fuchs UB2000-F42-I-V15 is an ultrasonic sensor designed for reliable non-contact distance and object detection. It provides an analog 4–20 mA output, teach-in functionality, temperature compensation and adjustable operating modes for industrial automation applications.
For PEPPERL+FUCHS ULTRASONIC SENSOR UB2000-F42-I-V15 IN CHENNAI, SCALAR AUTOMATION, located in Ahmedabad, provides Pepperl+Fuchs sensing solutions for machine automation, process monitoring and industrial control applications.
| Parameter | Specification |
|---|---|
| Product | UB2000-F42-I-V15 |
| Sensor Type | Ultrasonic |
| System | Single head |
| Sensing Range | 60–2000 mm |
| Adjustment Range | 90–2000 mm |
| Dead Band | 0–60 mm |
| Output | 1 × Analog 4–20 mA |
| Operating Voltage | 10–30 V DC |
| Resolution | 0.7 mm |
| Repeat Accuracy | ±0.1% of full-scale value |
| Characteristic Deviation | ±1% of full-scale value |
| Load Impedance | 0–300 Ω |
| Transducer Frequency | Approx. 175 kHz |
| Response Delay | Approx. 150 ms |
| Connection | M12 × 1, 5-pin |
| Operating Temperature | -25°C to +70°C |
| Housing | ABS |
| Dimensions | 80 × 80 × 34 mm |
The manufacturer specifies a 60–2000 mm sensing range, 4–20 mA analog output, 10–30 V DC supply and 0.7 mm resolution for the UB2000-F42-I-V15.
● Non-contact ultrasonic measurement
● Analog 4–20 mA output for PLC and automation systems
● Teach-in function for convenient setup
● Temperature compensation
● Adjustable sound-cone divergence
● Synchronization capability for multiple sensors
● Adjustable operating mode
● Small unusable area
● LED indicators for power, object detection and fault status
● Suitable for continuous industrial distance measurement
● Level measurement
● Object detection
● Distance monitoring
● Material handling systems
● Conveyor automation
● Packaging machinery
● Tank and vessel monitoring
● Position detection
● Industrial process automation
● Machine control systems
The UB2000-F42-I-V15 can provide an analog distance signal to a PLC or control system, making it suitable for applications where continuous object or level measurement is required.
SCALAR AUTOMATION supports PEPPERL+FUCHS ULTRASONIC SENSOR UB2000-F42-I-V15 IN CHENNAI requirements for industrial sensing, machine automation and control-panel applications.
