Details of PEPPERL+FUCHS ULTRASONIC SENSORS

The Pepperl+Fuchs UB2000-F42-I-V15 is an ultrasonic sensor developed for accurate, non-contact distance measurement and object detection in industrial automation systems. Its analog 4–20 mA output, wide sensing range and teach-in functionality make it suitable for continuous measurement applications.

For UB2000-F42-I-V15 SENSOR SUPPLIER IN AHMEDABAD, SCALAR AUTOMATION, located in Ahmedabad, offers industrial automation sensing solutions for machine builders, control-panel integrators and manufacturing industries.



UB2000-F42-I-V15 Specifications

ParameterDetails
ModelUB2000-F42-I-V15
Sensor TypeUltrasonic Sensor
SystemSingle Head
Sensing Range60–2000 mm
Adjustment Range90–2000 mm
Dead Band0–60 mm
Output1 × Analog 4–20 mA
Operating Voltage10–30 V DC
Resolution0.7 mm
Characteristic Deviation±1% of Full-Scale Value
Repeat Accuracy±0.1% of Full-Scale Value
Transducer FrequencyApprox. 175 kHz
Response DelayApprox. 150 ms
Load Impedance0–300 Ω
ConnectionM12 × 1, 5-pin
ProtectionIP54
Operating Temperature-25°C to +70°C
Housing MaterialABS
Dimensions80 × 80 × 34 mm
WeightApprox. 140 g

The above specifications are based on the current Pepperl+Fuchs technical documentation.



Sensor Features

● Non-contact ultrasonic distance measurement

● 4–20 mA analog signal for PLC and control systems

● 60–2000 mm sensing capability

● TEACH-IN function for sensor setup

● Temperature compensation

● Adjustable operating mode

● Adjustable sound-cone divergence for interference suppression

● Bi-directional synchronization

● 0.7 mm resolution

● LED indication for operating and fault conditions

● Compact 80 × 80 × 34 mm housing

These features make the sensor suitable for integration with industrial PLC, HMI and automation control systems.



Typical Industrial Applications

● Material and object detection

● Continuous distance monitoring

● Level measurement

● Conveyor systems

● Packaging machinery

● Material handling equipment

● Position monitoring

● Machine automation

● Process measurement

● Industrial control panels



Why Use UB2000-F42-I-V15?

The UB2000-F42-I-V15 combines ultrasonic sensing with an analog 4–20 mA interface, allowing measured distance information to be integrated into PLC-based automation systems. Its adjustable parameters, synchronization capability and temperature compensation support flexible industrial installations.

SCALAR AUTOMATION supports requirements for UB2000-F42-I-V15 SENSOR SUPPLIER IN AHMEDABAD for industrial automation, machine control and sensing applications.
