The Pepperl+Fuchs UB2000-F42-I-V15 is a single-head ultrasonic sensor designed for non-contact distance measurement and object detection in industrial automation. It provides a 60–2000 mm sensing range and an analog 4–20 mA output, making it suitable for continuous measurement and PLC-based control applications.
For PEPPERL+FUCHS ULTRASONIC SENSOR UB2000-F42-I-V15 IN KOLKATA, SCALAR AUTOMATION, located in Ahmedabad, provides industrial sensing solutions for machine builders, manufacturing industries, automation integrators and control-panel applications.
| Parameter | Specification |
|---|---|
| Model | UB2000-F42-I-V15 |
| Sensor Type | Ultrasonic Sensor |
| System | Single Head |
| Sensing Range | 60–2000 mm |
| Adjustment Range | 90–2000 mm |
| Dead Band | 0–60 mm |
| Standard Target Plate | 100 × 100 mm |
| Output | 1 × Analog 4–20 mA |
| Operating Voltage | 10–30 V DC |
| Resolution | 0.7 mm |
| Characteristic Deviation | ±1% of Full-Scale Value |
| Repeat Accuracy | ±0.1% of Full-Scale Value |
| Transducer Frequency | Approx. 175 kHz |
| Response Delay | Approx. 150 ms |
| Load Impedance | 0–300 Ω |
| Connection | M12 × 1, 5-pin |
| Protection Rating | IP54 |
| Operating Temperature | -25°C to +70°C |
| Housing | ABS |
| Dimensions | 80 × 80 × 34 mm |
| Weight | Approx. 140 g |
The above specifications are from the Pepperl+Fuchs technical documentation for this model.
● Non-contact ultrasonic distance measurement
● 60–2000 mm sensing capability
● Analog 4–20 mA output
● 0.7 mm resolution
● TEACH-IN functionality
● Temperature compensation
● Adjustable operating mode
● Adjustable sound-cone divergence
● Bi-directional synchronization
● Interference suppression
● LED indication for operating and fault conditions
● Compact single-head construction
● Conveyor and material handling systems
● Packaging machinery
● Level measurement
● Object detection
● Distance monitoring
● Position sensing
● Production machinery
● Process monitoring
● Machine automation
● Industrial control panels
● PLC-based measurement systems
The 4–20 mA analog output allows distance information to be transferred to a compatible PLC, controller or automation system for continuous monitoring and process control.
