The Pepperl+Fuchs UB2000-F42-I-V15 is a single-head ultrasonic sensor developed for non-contact distance measurement and object detection in industrial automation. It offers a 60–2000 mm sensing range with an analog 4–20 mA output, allowing measured distance values to be integrated into PLC and control systems.
For PEPPERL+FUCHS ULTRASONIC SENSOR UB2000-F42-I-V15 IN MUMBAI, SCALAR AUTOMATION, located in Ahmedabad, provides industrial sensing solutions for machine manufacturers, automation integrators, production industries and control-panel applications.
| Parameter | Specification |
|---|---|
| Product Model | UB2000-F42-I-V15 |
| Sensor Principle | Ultrasonic |
| System | Single Head |
| Sensing Range | 60–2000 mm |
| Adjustment Range | 90–2000 mm |
| Dead Band | 0–60 mm |
| Standard Target Plate | 100 × 100 mm |
| Output | 1 × Analog 4–20 mA |
| Supply Voltage | 10–30 V DC |
| Resolution | 0.7 mm |
| Characteristic Deviation | ±1% of Full-Scale Value |
| Repeat Accuracy | ±0.1% of Full-Scale Value |
| Transducer Frequency | Approx. 175 kHz |
| Response Delay | Approx. 150 ms |
| Load Impedance | 0–300 Ω |
| Connection | M12 × 1, 5-pin |
| Protection Rating | IP54 |
| Operating Temperature | -25°C to +70°C |
| Housing | ABS |
| Dimensions | 80 × 80 × 34 mm |
| Weight | Approx. 140 g |
The manufacturer specifies these electrical, mechanical and sensing characteristics for the UB2000-F42-I-V15.
● Non-contact ultrasonic measurement
● Wide 60–2000 mm sensing range
● Analog 4–20 mA output
● 0.7 mm resolution
● TEACH-IN functionality
● Temperature compensation
● Adjustable mode of operation
● Adjustable sound-cone divergence
● Interference suppression
● Bi-directional synchronization
● LED operating and fault indication
● Compact single-head construction
● Object and distance detection
● Level measurement
● Conveyor automation
● Packaging machines
● Material handling systems
● Position monitoring
● Production machinery
● Process monitoring
● Machine automation
● Industrial control panels
● PLC-based measurement systems
The 4–20 mA analog output makes the sensor suitable for continuous measurement applications where distance information needs to be transmitted to a PLC, controller or compatible automation device.
The UB2000-F42-I-V15 can be used as part of an industrial sensing system where reliable, non-contact measurement is required. Its teach-in function, temperature compensation and synchronization options provide flexibility during machine installation and commissioning.
For PEPPERL+FUCHS ULTRASONIC SENSOR UB2000-F42-I-V15 IN MUMBAI, SCALAR AUTOMATION supports requirements for ultrasonic sensors, PLC integration, machine automation and industrial control applications.
