Details of PEPPERL+FUCHS ULTRASONIC SENSORS

The Pepperl+Fuchs UB2000-F42-I-V15 is an industrial ultrasonic sensor used for non-contact distance measurement, object detection and automated measurement tasks. Its analog current output, teach-in function and adjustable sensing parameters make it suitable for integration into compatible industrial control and monitoring systems.

For PEPPERL+FUCHS ULTRASONIC SENSOR UB2000-F42-I-V15 IN NOIDA, SCALAR AUTOMATION, located in Ahmedabad, provides industrial automation products and sensing solutions for machinery manufacturers, production facilities, automation integrators and electrical control-panel applications.



Technical Specifications

ParameterSpecification
ManufacturerPepperl+Fuchs
Model NumberUB2000-F42-I-V15
Sensor TypeUltrasonic Sensor
System ConfigurationSingle Head
Sensing Range60–2000 mm
Adjustment Range90–2000 mm
Dead Band0–60 mm
Standard Target Plate100 × 100 mm
Analog Output4–20 mA
Operating Voltage10–30 V DC
Resolution0.7 mm
Characteristic Deviation±1% of full-scale value
Repeat Accuracy±0.1% of full-scale value
Transducer FrequencyApprox. 175 kHz
Response DelayApprox. 150 ms
Load Impedance0–300 Ω
Electrical ConnectionM12 × 1, 5-pin
Protection RatingIP54
Operating Temperature-25°C to +70°C
Housing MaterialABS
Dimensions80 × 80 × 34 mm
WeightApprox. 140 g





Sensor Features

● Non-contact distance measurement – Detects target distance without direct physical contact.

● 60–2000 mm sensing range – Supports distance measurement across a wide operating range.

● 4–20 mA analog signal – Allows measured values to be transferred to compatible PLC analog inputs and control equipment.

● TEACH-IN function – Facilitates configuration of the sensor's evaluation limits.

● Temperature compensation – Helps manage temperature-related effects on measurement.

● Adjustable sound-cone divergence – Supports adaptation of the sensing field to the installation.

● Synchronization facility – Enables coordinated operation in suitable installations involving multiple sensors.

● LED status indication – Provides visual information about power, object detection, programming and fault conditions.



Industrial Applications

● Conveyor and material-handling machinery

● Distance and position monitoring

● Object detection systems

● Packaging and processing equipment

● Continuous level measurement

● Automated production lines

● Material positioning systems

● Industrial measurement equipment

● Process monitoring applications

● PLC-based machine-control systems
