The Pepperl+Fuchs UB2000-F42-I-V15 is a single-head ultrasonic sensor designed for non-contact distance measurement and object detection. It features an analog 4–20 mA output, teach-in functionality, temperature compensation and adjustable sound-cone characteristics for industrial automation applications.
For PEPPERL+FUCHS ULTRASONIC SENSOR UB2000-F42-I-V15 IN DELHI, SCALAR AUTOMATION, located in Ahmedabad, provides industrial automation and sensing solutions for machine builders, manufacturers, system integrators and control-panel applications.
| Parameter | Specification |
|---|---|
| Model | UB2000-F42-I-V15 |
| Sensor Type | Ultrasonic Sensor |
| System | Single Head |
| Sensing Range | 60–2000 mm |
| Adjustment Range | 90–2000 mm |
| Dead Band | 0–60 mm |
| Standard Target Plate | 100 × 100 mm |
| Output | 1 × Analog 4–20 mA |
| Operating Voltage | 10–30 V DC |
| Resolution | 0.7 mm |
| Characteristic Deviation | ±1% of Full-Scale Value |
| Repeat Accuracy | ±0.1% of Full-Scale Value |
| Transducer Frequency | Approx. 175 kHz |
| Response Delay | Approx. 150 ms |
| Load Impedance | 0–300 Ω |
| Connection | M12 × 1, 5-pin |
| Protection Rating | IP54 |
| Operating Temperature | -25°C to +70°C |
| Housing | ABS |
| Dimensions | 80 × 80 × 34 mm |
| Weight | Approx. 140 g |
● Non-contact ultrasonic distance measurement
● 60–2000 mm sensing range
● Analog 4–20 mA signal
● 0.7 mm resolution
● TEACH-IN functionality
● Temperature compensation
● Adjustable operating mode
● Adjustable sound-cone divergence
● Bi-directional synchronization
● LED status indication
● Compact single-head construction
● Integration with PLC-based automation systems
● Object and distance detection
● Level measurement
● Conveyor automation
● Packaging machinery
● Material handling systems
● Position monitoring
● Machine automation
● Production lines
● Process monitoring
● Industrial control systems
The analog 4–20 mA output enables the measured distance to be transferred to a compatible PLC or control system for continuous monitoring and automation.
The UB2000-F42-I-V15 can be incorporated into PLC-based control architectures where continuous ultrasonic distance information is required. Its synchronization options can also support installations involving multiple ultrasonic sensors.
SCALAR AUTOMATION supports requirements for PEPPERL+FUCHS ULTRASONIC SENSOR UB2000-F42-I-V15 IN DELHI for industrial sensing, machine automation and control-panel projects.
